Hello World

Welcome and thank you for your interest in this project. To get started publishing blog posts, fixing issues or adding new features, please read first the the instructions below.

Creating blog contents

Setup blog post directory

Add a directory to content that follows this name template:

YYYY-MM-DD-the-title-of-the-blog-post

The name consist of the year (YYYY), the month (MM), the day (DD) and the title of the blog post where every character is lowercased and spaces and other characters are changed into dashes. For example:

2012-12-12-the-end-of-the-world

This means the blog post is published on December 12, 2012 and its title is "The End of the World". Please ensure that every word is separated only by a single dash (-).

Inside this directory, create a new file called index.md. You can use the example file (index.md.example) as a base for your blog post.

Writing with Markdown

Markdown is the markup language that we'll use to create blog posts. If you're not familiar with the syntax you can see the following links:

Update blog post frontmatter

Inside index.md.example you will find a section at the top that starts and ends with three dashes:

---
title: The End of the World
author: rmjordas
date: '2012-12-12'
image: ./hero.jpg
tags:
  - cute
  - scary
---

This section is called the frontmatter and it contains the most essential information needed when creating the static page for a single blog post.

  • title - Title of your blog post, this will be the text shown inside the hero image and it is included in the <title> of the HTML document for this blog post.
  • author - A unique ID for the author of the blog post. Please refer to Add an author section for instructions on how to create an author entry.
  • date - The date when the blog post was published. This follows a special format: YYYY-MM-DDTHH:mm:sss+/-TT:TT where hours (HH), minutes (mm), seconds (sss), and timezone offset (+/-TT:TT) are optional.
  • image - Hero image for the blog post that contains the title of the blog post positioned at the top of the page below the navigation.
  • tags - A list of words and/or phrases that can summarize the main topics of the blog post.

Add images and other assets

To include images to your blog post, simply place them in the directory you created and refer to them using Markdown syntax.

## How to add images to your blog post

This is the syntax:

![This is the alternative text](./my-image.jpg)

Some text here.

Example

![pu](https://avatars3.githubusercontent.com/u/41756078)

pu

NOTE: Some image formats may not be recognized by the image transformer plugin, so it is best to stick to the common formats like: jpg (or jpeg), png, gif, svg, etc.

You can also add a hero image to your blog post. Similar to the other images, you put this file inside the same directory but you add a reference to it on the frontmatter of your index.md file. In the example below, the banner image is reference in the image field. If you have not provided a value for this field, a default image will be used instead.

---
title: The End of the World
author: rmjordas
date: '2012-12-12'
image: ./hero.jpg
---

## The Year 2k12

Text goes here

Syntax highlighting

To use syntax aware highlighting to your code blocks, insert the language name after the opening code block syntax (```):

```graphql
query SiteMetadataQuery {
  site {
    siteMetadata {
      title
      description
      url
      twitter
    }
  }
}
```

You can view the list of supported languages in Prism's website.

Add an author

You must be listed as an author before you can post. In the content directory, there is a file called author.yaml. Here you add an entry with these options:

  • id (Required) - A unique string value for this author entry. These are the rules for this value:

    • May only contain alphanumeric characters or hyphens
    • Cannot have multiple consecutive hyphens
    • Cannot begin or end with a hyphen
    • Maximum is 39 characters
  • name (Required) - The author's display name
  • bio - Short description of the author
  • github - The author's GitHub username
  • twitter - The author's Twitter username
  • avatar - The path for the image the the author would like to use as their avatar image. Please make sure to add the image file in the content/assets directory with the same file name as the id above. For example if the author id is rmjordas, then the value should be assets/rmjordas.png. If you don't provide a value for this option, a default avatar image will be used.

Add a page

You are not limited to just adding blog posts. If you like to have a landing page of sorts for your project or something, you can. So we can have pages for these paths: /help, /grocerhub, /slack-invite, etc.

A page can be very simple and can be crammed into one file, e.g. 404.tsx, index.tsx (this file creates Pub's landing page), tags.tsx, etc..

For now, the process of adding pages is not as streamlined as there are a lot of considerations like: How can a user reach that page, or are we going to change the layout of pages to add a component that links to that page, i.e. navigation components, etc. It can potentially change the design of the website. Also, adding pages require that you know React, TypeScript and GraphQL.

Simple pages

If you want to add a simple page, just add a React component in the pages directory. If you want a /help page, you should name this file help.tsx. If you want a page on /grocerhub/devs, first create a new directory in /src/pages called "grocerhub" and inside that directory add devs.tsx.

Consider this file created at pages/ called my-page.tsx:

import * as React from 'react';

interface OwnProps {
  name?: string;
}

type MyPageProps = OwnProps;

const MyPage: React.FC<MyPageProps> = ({ name = 'Uny' }) => (
  <h1>Welcome to {name}</h1>
);

export default MyPage;

Once you build your app, you can view this page on /my-page. This page displays a very basic page where there's only a heading element as its content.

Most likely you would need to also show the top navigation and footer. These can be added by importing the Layout component. Wrap your content inside this component.

To update the values of elements in the <head />, you should use the Seo component. You can put this anywhere the component heirarchy.

import * as React from 'react';

import { Layout, Seo } from '@components/shared';

// ...

const MyPage: React.FC<MyPageProps> = ({ name = 'Uny' }) => (
  <React.Fragment>
    <Seo title="My page" />

    <Layout>
      <h1>Welcome to {name}</h1>
    </Layout>
  </React.Fragment>
);

export default MyPage;

You would notice that we're using the default export in components. Although we can do named export, i.e. export const MyPage = () => (); on some components, Gatsby requires templates to use default export. Rather than use a mix of named and default exports, the project strictly enforces the rule that all components must use the default export syntax to avoid confusion.

Advanced pages

Once your component requires data from some source, e.g. the project's URL, the author of the blog post, etc., you must define the query that this component will perform on build.

The most basic query you can add to your page is "static query". These could be data about the website, e.g. name, description, etc..

query {
  file(relativePath: { eq: "default-post-image.jpg" }) {
    childImageSharp {
      fluid(maxWidth: 1800) {
        ...GatsbyImageSharpFluid
      }
    }
  }
}

The query above will get an image called default-post.image.jpg. Since this is defined to be fluid image Gatsby will optimize this image by creating various versions. To use this you need to import a special element from gatsby-image called Img and pass the value of data.file.childImageSharp.fluid to the fluid attribute.

import { graphql } from 'gatsby';
import { Img, FluidObject } from 'gatsby-image';
import * as React from 'react';

interface SomeComponentProps {
  data: {
    file: {
      childImageSharp: {
        fluid: FluidObject;
      };
    };
  };
}

export const defaultPostImageQuery = graphql`
  query {
    file(relativePath: { eq: "default-post-image.jpg" }) {
      childImageSharp {
        fluid(maxWidth: 1800) {
          ...GatsbyImageSharpFluid
        }
      }
    }
  }
`;

const SomeComponent: React.FC<SomeComponentProps> = ({ data }) => (
  <Img fluid={data.file.childImageSharp.fluid} />
);

export default SomeComponent;

Some queries are quite common that these were extracted to their own custom React hook. The above query is equivalent to using the useDefaultPostImage React hook:

import { Img } from 'gatsby-image';
import * as React from 'react';

import { useDefaultAvatarImage } from '@hooks';

const SomeComponent: React.FC = () => {
  const defaultAvatarImage = useDefaultAvatarImage();

  return <Img fluid={defaultAvatarImage.childImageSharp.fluid} />;
};

export default SomeComponent;

Even more advance pages

When you need to display a list of something, say, a list of recent blog posts, the process is more involved. First you would define a page template in the templates/ directory. This component is similar to other pages you will make except for the format of the query it exports (we'll go into detail later).

Next step is to tell Gatsby that you want to create this page. Gatsby does not care about components outside the pages/ directory by default. You can either configure Gatsby to watch a directory (e.g. pages/) or explicitly call a method to create this page.

The Gatsby's Node API configuration file is located at <rootDir>/gatsby-node.js and this is where we'll tell Gatsby to create the pages. The snippet below will create a single page that can be accessed at /blogpostlist.

const path = require('path');

exports.createPages = ({ actions }) => {
  actions.createPage({
    path: '/blogpostlist',
    component: path.resolve('./src/templates/blog.tsx'),
    context: {
      limit: 6,
      skip: 0,
    },
  });
};

The exported createPages anonymous function is passed an object when Gatsby builds the app. The method we need is inside the the actions field inside this object.

The createPage Action

Inside the exported createPages anonymous function, we call graphql from the destructured parameters, and pass it a template literal containing the a query. This query could contain

exports.createPages = ({ graphql, actions }) => {
  const { createPage } = actions;

  const loadBlogPosts = new Promise((resolve, reject) => {
    graphql(`
      {
        allMarkdownRemark(
          sort: { fields: [frontmatter___date], order: DESC }
          limit: 1000
        ) {
          nodes {
            frontmatter {
              title
            }
          }
        }
      }
    `).then(({ errors, data }) => {
      if (errors) {
        reject(errors);
      }
    });

    createPage({
      path: '/blog',
      component: template.blog,
      context: { limit: 6, skip: 0 },
    });

    resolve();
  });

  return Promise.all([loadBlogPosts]);
};

Development

NOTE: This section is not yet finalized.

Requirements

Ensure you have the following installed in your system:

  • Node.js
  • npm
  • git

When you install Git on Windows, you are also provided with Git Bash. It is recommended to use this software when interacting with Git. This guide will assume that you are using Git Bash if you are using Windows. On Linux and Mac, the default terminal will do.

To verify your installations, enter the following in your terminal:

$  node -v;npm -v;git --version
v8.12.0
6.4.1
git version 2.19.1.windows.1

You should see something similar to the output above.

Clone to your machine

Open you terminal and clone the repository by typing:

git clone git@github.com:projectunic0rn/pub.git
cd pub
pwd # $PROJECT_ROOT

The first command will clone the project to your machine. This means that you tell Git to make a directory in the directory where you executed the clone command and copy the repository there. If you have a dedicated directory for cloned repository, make sure you are running your commands inside that directory.

The next command will allow you to move inside the directory that Git created, when it cloned the repo to your machine: pub (same as the repository's name).

NOTE: You can provide the name of the directory by adding it to the last part of the clone command:

git clone git@github.com:projectunic0rn/pub.git more-awesome-pub

The last command will output the path to the current working directory. In this guide, we refer to the root of the Pub repository as $PROJECT_ROOT.

Running npm scripts

Before you can inspect the app in your browser, you have to first download some packages that this project requires. You can see a list of dependencies inside the file called package.json.

The npm executable provides a command to download all the project's dependencies:

pwd # You must be in the $PROJECT_ROOT
npm install

This will grab all the packages and put it inside a node_modules directory in the $PROJECT_ROOT.

After that, you can now run the app by executing this command in you terminal

pwd # $PROJECT_ROOT
npm run dev

Finally, open your browser to http://localhost:8000.

Other commands

The project also specifies other npm scripts you can run when working with specific portions of the application:

Script Description
build Creates static build for deployment
clean Deletes the .cache and public directories
dev Starts a development server
dev:m Starts a development server connected to LAN
format Formats the JSON and markdown files according to Prettier rules
format:precommit Formats the staged files according to Prettier rules
lint Checks for lint errors
lint:fix Checks for lint errors and automatically fix them
start Serves the production build for testing
test Run tests
typecheck Runs TypeScript compiler to check source for type errors

Quick start

These steps will guide you through contributing to this project:

  • Fork the repo
  • Clone your fork and install dependencies
git clone https://github.com/<your-github-username>/pub.git
npm install

Make and commit your changes. Make sure the commands npm run build and npm run test are working.

Send a pull request and include a short summary of your changes.

About Pull Requests

Environment Variables

Environment variables can be added in an .env as key-value pairs following this syntax: EXAMPLE_KEY="a value" (See .env.example).

WARNING: You should not put sensitive values in .env. These values are bundled together with the application and anyone can inspect them.

Gatsby Telemetry

Gatsby added telemetry when they release version 2.3.0. You can disable this by running:

gatsby telemetry --disable

Alternatively, you may set GATSBY_TELEMETRY_DISABLED to 1 on the project .env file:

GATSBY_TELEMETRY_DISABLED=1

NOTE: You might also need to restart the development server when you change the .env.

Troubleshooting

Commiting changes to Git fails and deletes my changes from my file system

Not sure what is the exact cause of this but this could happen if you are running a local Gatsby development server, and you trigger the pre-commit hook (by running git commit). The pre-commit hook will process your changes and run type checks and some formatting. These actions probably overwhelms the Node.js process for some reason and deletes the changes along with other files.

When this happens, you can still recover the deleted files that commited to Git, but all new changes will be lost (unless you have some program that tracks changes to files, e.g. Dropbox history, etc.).

For very large diffs, it is advisable to shut down the Gatsby local development server first before commiting to Git.

Everything runs slow when I'm editing with Visual Studio Code

There is a TypeScript release that caused type checking to run 20x slower on projects that use Styled Components type definitions. To fix this, please make sure you that your editor is using the same TypeScript version as the project. Refer to the bottom right portion of the status bar when you have an open TypeScript file. To change this value, click the version value and pick "Use Workspace Version" on the dropdown.

Maintenance

Dependencies

Packages are pinned to a specific version, thus you might need to run an update every now and then. Run npm oudated to check which packages are not in their latest versions. You may choose to update all packages or just some: maybe those that release MAJOR or MINOR but not PATCH versions.

If you do update, make sure to do checks to see if it broke something in the app. Run all the test suites to see if something fails, then generate a production build using npm run build and see if there are any build errors. You can delete Gatsby artifacts in .cache and public by running npm run clean and run the checks again if you're still having trouble.

NOTE: Don't forget to also commit changes in package-lock.json!

When you updgrade the Node.js version, be sure to check if the Travis configuration matches the MAJOR version, i.e. 7, 10, 11. You don't need to specify the MINOR and PATCH versions.

# Update the value in this part of `travis.yml`
node_js:
  - '10'
